KYMCO electrical part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
31100-AGE2-EZ5 | AC GEN ASS'Y | $352.29 | 2 |
 |
31100-ALG1-E10 | AC GEN ASSY | $523.71 | 19 |
 |
31100-ALG2-E10 | AC GEN ASSY | $268.71 | 4 |
 |
31100-ALH3-90B | AC GEN ASSY | $315.06 | 10 |
 |
31100-KEB7-90B | AC GEN ASSY (D406) | $458.76 | 35 |
 |
31100-KED9-900 | AC GEN ASSY (D402) | $450.96 | 27 |
 |
31100-KHB4-90A | A .C. GEN. ASSY. | $296.76 | 30 |
 |
31100-KHC5-E1B | AC GEN ASSY | $346.74 | 3 |
 |
31100-KHD8-B0A | AC GEN ASSY(CDI) | $410.85 | 23 |
 |
31100-KHE7-90A | AC GEN ASSY | $458.76 | 35 |
 |
31100-KKC4-90A | AC GEN ASSY | $438.93 | 7 |
 |
31100-KKD6-E0A | AC GEN ASSY | $346.02 | 40 |
 |
31100-KKE5-E00 | AC GEN ASSY (D402) | $730.60 | 6 |
 |
31100-KSBS-941 | AC GEN ASSY | $346.74 | 18 |
 |
31100-KUDU-C00 | AC GEN ASSY | $187.53 | 20 |
 |
31100-LBA7-90B | AC GEN ASSY | $407.16 | 62 |
 |
31100-LBC9-90A | A .C. GEN. ASSY. | $260.64 | 61 |
 |
31100-LBD4-900 | AC GEN ASSY (D402) | $220.80 | 52 |
 |
31100-LBD6-C00 | AC GEN ASSY | $191.52 | 4 |
 |
31100-LBD6-E0B | AC GEN ASSY | $346.74 | 12 |
 |
31100-LBD6-E0C | AC GEN ASSY | $346.74 | 33 |
 |
31100-LCA4-E0B | AC GEN ASSY | $453.57 | 10 |
 |
31100-LCA4-E80 | AC GEN ASSY | $453.57 | 43 |
 |
31100-LCD3-M3A | AC GEN ASSY | $406.50 | 38 |
 |
31100-LDB2-E00 | AC GEN ASSY (D406) | $458.76 | 13 |
 |
31100-LDB5-E01 | A .C. GEN. ASSY. | $545.13 | 91 |
 |
31100-LDC8-E11 | AC GEN ASSY | $167.10 | 31 |
 |
31100-LDE9-E00 | AC GEN ASS'Y | $349.50 | 122 |
 |
31100-LDG7-900 | AC GEN ASS'Y | $563.82 | 14 |
 |
31100-LDH1-E00 | AC GEN ASSY | $358.50 | 12 |
 |
31100-LEA1-90A | AC GEN ASS'Y | $353.55 | 32 |
 |
31100-LEA6-90A | A .C. GEN. ASSY. | $436.86 | 18 |
 |
31100-LEA7-E0B | AC GEN ASSY | $375.09 | 42 |
 |
31100-LEC8-E0A | AC GEN. ASSY | $408.72 | 2 |
 |
31100-LEJ2-M30 | AC GEN ASSY | $180.75 | 8 |
 |
31100-LFA5-E00 | AC GEN ASSY | $541.20 | 34 |
 |
31100-LFB5-90A | AC GEN ASSY | $348.24 | 10 |
 |
31100-LGS6-E10 | AC GEN ASSY | $255.81 | 16 |
 |
31100-LHA2-M30 | AC GEN ASSY | $294.96 | 9 |
 |
31100-LHB3-M30 | AC GEN ASSY | $203.58 | 16 |
 |
31100-LKA8-E0A | AC GEN ASSY | $555.03 | 134 |
 |
31100-LKF5-E01 | AC GEN ASSY. | $455.56 | 2 |
 |
31100-LKM5-E00 | A.C.GEN. ASSY | $616.62 | 59 |
 |
31100-LKM8-900 | AC GEN ASSY/ D406 | $429.93 | 56 |
 |
3110A-LKL5-E30 | ACG. & ONE WAY COMP. ASSY. | $257.25 | 12 |
 |
31110-ABD2-C00 | FLYWHEEL COMP. | $168.54 | 13 |
 |
31110-ABD2-EZ5 | ROTOR. FLYWHEEL | Ask about this part → | 2 |
 |
31110-ACC1-E10 | FLYWHEEL COMP | $168.27 | 36 |
 |
31110-ADA1-E00 | FLYWHEEL COMP (D406) | $403.04 | 15 |
 |
31110-ADB2-C00 | FLYWHEEL COMP | $168.30 | 13 |
Common questions
How do I know an electrical part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO electrical parts?
Yes — all 1,748 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
