KYMCO frame & footrest part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
50230-AEC7-E00 | LIMIT VELOCITY PLATE | $27.18 | 2 |
 |
50244-LEE8-E00 | BRKT THERMOSTAT | $19.26 | 215 |
 |
50261-KKE5-E00 | HEAT GUARD PIPE | $49.47 | 6 |
 |
50262-KKE5-E00 | SPONGE PIPE A | $10.80 | 6 |
 |
50263-KKE5-E00 | SPONGE PIPE B | $10.80 | 6 |
 |
50264-KKE5-E00 | SPONGE PIPE C | $8.49 | 6 |
 |
50266-PWB1-900 | BRACKET MOUNTING SOLENOID | $11.46 | 28 |
 |
50300-KED9-900-BJS | PLATE R PIVOT COVER | $108.21 | 4 |
 |
50300-KED9-900-N1S | PLATE R PIVOT COVER | $138.96 | 3 |
 |
50300-KED9-900-NZS | PLATE R PIVOT COVER | $108.21 | 3 |
 |
50300-KED9-900-PGS | PLATE R PIVOT COVER | $108.21 | 3 |
 |
50300-KED9-900-R7S | PLATE R PIVOT COVER | $91.83 | 2 |
 |
50300-KED9-900-RDS | PLATE R PIVOT COVER | $108.21 | 3 |
 |
50300-KED9-900-V3S | PLATE R PIVOT COVER | $108.21 | 3 |
 |
50300-KED9-900-Y5S | PLATE R PIVOT COVER | $119.49 | 2 |
 |
50300-KED9-M30-BJS | PLATE R PIVOT COVER | $87.33 | 1 |
 |
50300-KED9-M30-NZS | PLATE R PIVOT COVER | $87.33 | 1 |
 |
50300-KED9-M30-PGS | PLATE R PIVOT COVER | $138.96 | 1 |
 |
50300-KED9-M30-RDS | PLATE R PIVOT COVER | $87.33 | 1 |
 |
50300-KED9-M30-V3S | PLATE R PIVOT COVER | $138.96 | 1 |
 |
50300-KED9-M30-Y5S | PLATE R PIVOT COVER | $87.33 | 1 |
 |
50301-0A41-011 | RACE STEERING BALL | $25.35 | 12 |
 |
50301-GLM0-001 | RACE UP STRG BALL | $26.01 | 117 |
 |
50301-GLM0-C00 | RACE UPPER STRG BALL | $16.08 | 11 |
 |
50301-KED9-900 | RACE STRG BALL TOP | $31.20 | 13 |
 |
50301-KGN7-671 | RACE UP STRG BALL | $35.34 | 5 |
 |
50301-KGN7-680 | RACE UP STRG BALL | $23.55 | 257 |
 |
50301-KGN7-C00 | RACE UP STRG BALL | $18.57 | 186 |
 |
50301-KKE5-E00 | COLLAR ENG MOUNT | $22.50 | 6 |
 |
50301-LBA8-C10 | CARBURETOR ASSY | $20.40 | 12 |
 |
50302-2H68-011 | RACE (STRG BOT) BALL | $33.66 | 257 |
 |
50302-2H68-C00 | RACE (STRG BOT) BALL | $15.84 | 197 |
 |
50302-KED9-900 | RACE STRG BALL BOP | $31.20 | 13 |
 |
50302-LBA8-C10 | RACE BOT STRG BALL | $22.50 | 12 |
 |
50305-GHC8-004 | RACE (UNDER STR ) BALL | $17.46 | 117 |
 |
50306-1F96-001 | NUT STRG STEM LOCK | $17.28 | 482 |
 |
50306-1F96-C00 | NUT STRG STEM LOCK | $12.12 | 220 |
 |
50306-AKB8-E00 | NUT STRG STEM LOCK | $17.28 | 2 |
 |
50306-KCAC-900 | NUT STRG STEM LOCK | $21.99 | 18 |
 |
50306-LBA7-900 | NUT REAR SHAFT | $39.36 | 137 |
 |
50306-LLB1-900 | NUT REAR SHAFT | $25.56 | 72 |
 |
50306-PTA7-900 | NUT RR AXLE SHAFT 28MM | $46.20 | 53 |
 |
50307-KED9-900 | BRKT R ENG HANGER FR | $23.37 | 27 |
 |
50307-LBA7-900 | COLLAR REAR SHAFT | $17.82 | 137 |
 |
50308-KED9-900 | BRKT L ENG HANGER FR | $23.37 | 27 |
 |
50310-KED9-900-BJS | PLATE L PIVOT COVER | $115.17 | 4 |
 |
50310-KED9-900-N1S | PLATE L PIVOT COVER | $138.96 | 3 |
 |
50310-KED9-900-NZS | PLATE L PIVOT COVER | $115.17 | 3 |
 |
50310-KED9-900-PGS | PLATE L PIVOT COVER | $115.17 | 3 |
 |
50310-KED9-900-R7S | PLATE L PIVOT COVER | $115.17 | 2 |
Common questions
How do I know a frame & footrest part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO frame & footrest parts?
Yes — all 1,421 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
