KYMCO fuel & air intake part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
16136-KGC5-900 | SPRING ACCP DIAPHRAGM | $8.88 | 153 |
 |
16137-KGC5-900 | COLLAR LEVER | $3.00 | 7 |
 |
16137-LDB5-E00 | COLLAR LEVER | $12.09 | 67 |
 |
16137-LGM5-900 | COLLAR LEVER | $11.79 | 10 |
 |
16137-PTA1-800 | COLLAR LEVER | $14.31 | 439 |
 |
16138-KEC3-900 | SPRING IDLE ADJUST SCREW | $1.86 | 237 |
 |
16138-KEC3-C00 | SPG IDLE ADJ SCREW | $0.30 | 28 |
 |
16138-KGC5-900 | SPRING IDLE ADJUST SCREW | $2.04 | 48 |
 |
16138-KGC5-C00 | SPRING IDLE ADJUST SCREW | $4.59 | 27 |
 |
1614-819-2102 | TH SENSOR ASSY | $190.35 | 11 |
 |
1614-834-2100 | THROTTLE SENSOR | $221.19 | 29 |
 |
1614-850-2100 | THROTTLE SENSOR ASSY | $177.75 | 27 |
 |
1614-868-0000-S | THROTTLE POSITION SENSER | $311.85 | 81 |
 |
1614-870-2100 | TPS | $236.49 | 7 |
 |
1614-891-2104 | FUEL LEVER SENSOR ASSY | $134.82 | 16 |
 |
1614-906-0002 | MAP SENSOR | $215.76 | 81 |
 |
1614-A22C-0000-Y | FUEL LEVER SENSOR COMP | $269.52 | 58 |
 |
16140-KEC3-900 | CLIP FLOAT VALVE | $3.00 | 140 |
 |
16142-KEC3-900 | COVER ACV | $16.53 | 61 |
 |
16142-KEC3-C00 | COVER ACV | $15.51 | 35 |
 |
16142-KGC5-900 | COVER ACV | $16.14 | 123 |
 |
16142-KGC5-C00 | COVER ACV | $10.50 | 36 |
 |
16144-KG0-8910-M1 | TUBE RUBBER | $18.21 | 11 |
 |
16144-LDB5-700 | SPRING CHOKE | $9.78 | 45 |
 |
16145-MZ2-7800 | JOINT COLLAR | $17.46 | 74 |
 |
16150-KEC3-900 | SCREW COMP DRAIN | $17.46 | 140 |
 |
16152-KG8-9010-M1 | ARM PIN | $6.06 | 301 |
 |
16154-KEC3-900 | SCREW IDLE ADJUST | $16.14 | 48 |
 |
16154-KEC3-M30 | SCREW IDLE ADJ | $17.61 | 51 |
 |
16154-KGC5-M30 | SCREW IDLE ADJ | $27.93 | 61 |
 |
16154-KHE7-900 | SCREW IDLE ADJUST | $19.65 | 23 |
 |
16154-KHE7-M30 | SCREW IDEL ADJUST | $4.50 | 2 |
 |
16154-KKE3-900 | SCREW IDLE ADJUST | $27.39 | 62 |
 |
16154-KKE3-C00 | SCREW IDLE ADJUST | $13.62 | 9 |
 |
16154-KKE5-E00 | SCREW IDLE PILOT ADJUST | $17.97 | 6 |
 |
16154-LDB5-E00 | SCREW IDLE ADJUST | $41.97 | 67 |
 |
16154-LGM5-900 | SCREW.ISC ADJUST | $22.23 | 12 |
 |
16155-KG8-9010-M1 | FLOAT VALVE COMP | $48.24 | 10 |
 |
16160-KKE3-900 | STOPPER THROTTLE | $4.92 | 18 |
 |
16161-KKE5-E00 | PLUG SHAFT | $17.97 | 6 |
 |
16162-KG8-9010-M1 | DRAIN SCREW PAN | $14.70 | 377 |
 |
16162-KKE5-E00 | STAY FIX SENSOR MAP | $32.01 | 6 |
 |
16163-KCS-9200 | FLOAT CHAMBER GASKET | $7.89 | 133 |
 |
16163-KCW-0000 | FLOAT CHAMPER GASKET | $8.67 | 8 |
 |
16165-GY6-9000 | NEEDLE JET HOLDER | $19.80 | 8 |
 |
16165-KEC3-900 | DIAPHRAGM COMP | $23.40 | 52 |
 |
16165-KGC5-900 | DIAPHRAGM COMP | $22.74 | 131 |
 |
16165-KGC5-C00 | DIAPHRAGM COMP | $28.59 | 24 |
 |
16165-KKJ9-003 | NEEDLE JET HOLDER | $46.86 | 16 |
 |
16166-LDB5-700 | PISTON CHOKE | $17.82 | 6 |
Common questions
How do I know a fuel & air intake part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO fuel & air intake parts?
Yes — all 2,348 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
