KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
94601-15000 | CLIP PISTON PIN 15MM | $5.67 | 303 |
 |
94601-16000 | CLIP PISTON PIN 16MM | $5.67 | 27 |
 |
94601-17000 | CLIP PISTON PIN 17MM | $1.86 | 331 |
 |
94601-22000 | CLIP PISTON PIN 22MM | $1.86 | 266 |
 |
94601-33000 | CLIP PISTON PIN 33MM | $4.92 | 424 |
 |
94601-ALE8-E00 | CLIP 43mm | $13.95 | 53 |
 |
94601-KKE5-E01 | CLIP PISTON PIN | $5.46 | 12 |
 |
94601-LDB5-E00 | CIRCLIP 46.5mm | $4.92 | 91 |
 |
94601-LEA3-900 | CIRCLIP PISTON PIN | $4.92 | 16 |
 |
94601-LKM5-E00 | CLIP PISTON PIN | $7.26 | 160 |
 |
94601-PSA6-E00 | CIRCLIP PISTON PIN 20MM | $22.23 | 2 |
 |
94601-PWB1-900 | CIRCLIP PISTON PIN 20MM | $5.31 | 145 |
 |
94605-KEBE-900 | FORK BOLT | $41.10 | 180 |
 |
94605-KED9-900 | FORK BOLT | $30.51 | 27 |
 |
94605-KFA1-900 | FORK BOLT | $34.23 | 36 |
 |
94605-KHD8-900 | FORK BOLT | $32.01 | 70 |
 |
94605-KKAK-900 | FORK BOLT | $36.51 | 2 |
 |
94605-KKE5-E00 | FORK BOLT | $119.52 | 6 |
 |
94605-LBA2-E00 | FORK BOLT | $59.04 | 38 |
 |
94605-LDC8-E10 | FORK BOLT | $26.49 | 26 |
 |
94605-LFB5-900 | FORK BOLT CAP | $39.93 | 19 |
 |
94605-LGC6-E00 | FORK BOLT | $25.95 | 12 |
 |
94605-LKB9-910 | FORK BOLT CAP | $37.08 | 16 |
 |
94608-30000 | O-RING 23X2.4 | $5.37 | 222 |
 |
94608-ALB1-900 | O-RING 7.6 X 1.2 GEN SENSOR | $11.46 | 9 |
 |
94608-KKE5-E00 | O-RING | $9.84 | 6 |
 |
94608-LBA2-E00 | O-RING | $4.26 | 38 |
 |
94608-LCD3-E00 | O-RING | $4.92 | 62 |
 |
94608-LDC8-E10 | O-RING | $1.86 | 41 |
 |
94608-LEJ2-E10 | O-RING 23X2.4 | $4.92 | 71 |
 |
94608-LFB6-E00 | O-RING | $4.92 | 9 |
 |
94608-LKB9-900 | O-RING | $5.22 | 16 |
 |
94608-LKF5-E00 | O-RING | $22.23 | 2 |
 |
94608-LLJ3-C00 | O-RING | $2.61 | 15 |
 |
94608-LLJ3-E00 | O-RING | $4.92 | 71 |
 |
94611-PWB1-900 | CLIP DRUM SHAFT | $4.92 | 145 |
 |
94621-PWB1-900 | RING DRIVEN BEARING | $9.06 | 145 |
 |
95000-LEE8-E00 | HOSE VENT-GEARCASE(55.5mm) | $66.96 | 261 |
 |
95001-35050-40 | TUBE FUEL 3.5*50 | $4.92 | 7 |
 |
95001-35080-40 | TUBE FUEL 3.8*80 | $10.50 | 14 |
 |
95001-35100-40 | TUBE FUEL 3.5*100 | $5.22 | 38 |
 |
95001-35135-40 | TUBE FUEL 3.5*135 | $5.31 | 38 |
 |
95001-35140-40 | TUBE FUEL 3.5*140 | $10.50 | 7 |
 |
95001-35160-40 | TUBE FUEL 3.5*160 | $18.33 | 9 |
 |
95001-35180-40 | TUBE FUEL 3.8*180 | $9.39 | 38 |
 |
95001-35200-40 | TUBE FUEL 3.5*200 | $7.53 | 18 |
 |
95001-35225-40 | TUBE FUEL 3.5*225 | $7.23 | 33 |
 |
95001-35250-40 | TUBE FUEL 3.5*250 | $10.50 | 2 |
 |
95001-35280-40 | TUBE FUEL 3.5*280 | $13.77 | 7 |
 |
95001-35335-40 | TUBE FUEL 3.5*335 | $8.19 | 12 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
