KYMCO wheels & axles part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
42407-LFA5-900 | PIN DOWEL | $32.73 | 447 |
 |
42407-PWB1-900 | PIN DOWEL | $29.49 | 145 |
 |
42408-LDB5-E00 | SEAL-OIL OUTPUT | $81.36 | 25 |
 |
42408-LFA5-900 | COUPLER DRIVE | $153.39 | 63 |
 |
42408-LKC3-500 | COUPLER DRIVE | $120.06 | 382 |
 |
42408-LKC3-510 | COUPLER DRIVE | $65.73 | 37 |
 |
42408-PWB1-900 | COUPLE DRIVE | $153.39 | 145 |
 |
42409-LDB5-E00 | SEAL-OIL INPUT | $89.64 | 25 |
 |
42409-LFA5-900 | SHAFT SHUTTLE | $50.37 | 60 |
 |
42409-LKC3-500 | SHAFT E-LOCK SELECTOR | $89.34 | 384 |
 |
42409-PWB1-900 | SHAFT.SHUTTLE | $46.65 | 145 |
 |
42410-LDB5-E00 | BOLT-FLANGE HEX HEAD TYPE2 | $28.59 | 25 |
 |
42410-LFA5-900 | PLUG DRAIN MAG | $75.12 | 447 |
 |
42410-PWB1-900 | PLUG DRAIN-MAG | $117.24 | 107 |
 |
42411-LDB5-E00 | BRTHER-AIR | $26.76 | 25 |
 |
42411-LFA5-900 | O-RING 6*1.5 | $13.77 | 121 |
 |
42412-LDB5-E00 | PLUG-DRAIN | $47.04 | 25 |
 |
42412-LFA5-900 | TAG ID GEARCASE | $10.14 | 281 |
 |
42413-LDB5-E00 | WASHER-DRAIN PLUG | $10.53 | 25 |
 |
42413-LFA5-900 | GASKET FLANGE | $23.64 | 92 |
 |
42413-LKC3-500 | GASKET FLANGE | $39.81 | 384 |
 |
42413-PWB1-900 | GASKET FLANGE | $21.30 | 145 |
 |
42414-LFA5-900 | SHAFT SELECTOR | $132.06 | 63 |
 |
42414-LKC3-500 | SHAFT. SELECTOR | $30.12 | 384 |
 |
42414-PWB1-900 | SHAFT SELECTOR | $132.06 | 145 |
 |
42415-LDB5-E00 | COLLAR-DOWEL | $56.16 | 25 |
 |
42415-LFA5-900 | FORK SELECTOR | $165.69 | 63 |
 |
42415-LKC3-500 | FORK SELECTOR | $116.13 | 384 |
 |
42415-PWB1-900 | FORK SELECTOR | $172.59 | 145 |
 |
42416-LFA5-900 | SPRING RETURN 4WD | $2.73 | 63 |
 |
42416-LKC3-500 | COLLAR ACTUATOR | $6.78 | 384 |
 |
42416-PWB1-900 | SPRING RETURN-4WD | $16.08 | 145 |
 |
42418-LDB5-E00 | RIG-SNAP C TYPE1 | $36.51 | 25 |
 |
42418-LFA5-900 | O-RING 3*2MM | $0.81 | 63 |
 |
42418-PWB1-900 | O-RING 3X2MM | $11.46 | 145 |
 |
42419-LDB5-E00 | BRG BALL | $149.73 | 25 |
 |
42419-LFA5-900 | O-RING 150*2MM | $18.06 | 92 |
 |
42419-LKC3-500 | GASKET HOUSING | $26.37 | 384 |
 |
42419-PWB1-900 | O-RING 150X2MM | $29.52 | 145 |
 |
42420-LDB5-E00 | BRG-PINION DRIVE | $158.07 | 25 |
 |
42421-LDB5-E00 | PINION-DRIVE | $456.18 | 25 |
 |
42421-LFA5-900 | RING RETAINING (4mm EXT) | $13.17 | 63 |
 |
42421-PWB1-900 | RING RETAINING-EXT 4 | $11.46 | 145 |
 |
42422-LDB5-E00 | BRG-NEEDLE PINION | $88.32 | 25 |
 |
42422-LFA5-900 | RING RETAINING ONE | $28.35 | 447 |
 |
42422-PWB1-900 | RING RETAINING ONE | $25.56 | 145 |
 |
42423-LDB5-E00 | BRG-BALL OUTPUT | $129.12 | 25 |
 |
42423-LFA5-900 | RING RETAINING | $32.10 | 447 |
 |
42423-PWB1-900 | RING RETAINING | $28.95 | 145 |
 |
42424-LDB5-E00 | SLEEVE-CPLC | $146.19 | 25 |
Common questions
How do I know a wheels & axles part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO wheels & axles parts?
Yes — all 926 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
