KYMCO frame & footrest part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
5013A-LGC6-E00 | BODY ASSY. FR FRAME | $1234.74 | 10 |
 |
50140-KHC4-900 | PLATE FLOOR | $16.59 | 3 |
 |
50140-LEA2-900 | BRKT FLOOR | $110.34 | 32 |
 |
50143-AGJ5-E00 | BRKT, RADIATOR | $133.62 | 7 |
 |
50143-AKB8-E00 | BRKT RADIATO | Ask about this part → | 2 |
 |
50143-KED9-900 | STAY RADIATOR JOINT | $10.50 | 27 |
 |
50143-LGC6-E00 | BRKT RADIATOR | $191.73 | 10 |
 |
50144-ABC9-M00 | BRKT FRONT COVER | $25.95 | 45 |
 |
50144-AGJ5-E00 | FR. STAY, FLOOR PANEL | $135.90 | 7 |
 |
50144-BLD3-M00 | BRKT FRONT COVER | $25.95 | 2 |
 |
50144-KFA6-M00 | STAY REFLECTOR | $21.99 | 36 |
 |
50144-LBA2-E00 | BRKT THERMOSTAT | $19.26 | 25 |
 |
50144-LGC6-E00 | FR. STAY FLOOR PANEL | $156.93 | 12 |
 |
50144-PTA1-900 | BRKT THERMOSTAT STAY | $25.65 | 96 |
 |
50145-AGJ5-E00 | RR. STAY R, FLOOR PANEL | $26.04 | 7 |
 |
50145-AKB8-E00 | RR STAY R FLOOR PANEL | Ask about this part → | 2 |
 |
50145-LGC6-E00 | RR. STAY R FLOOR PANEL | $28.26 | 10 |
 |
50146-AKB8-E00 | RR STAY L FLOOR PANEL | Ask about this part → | 2 |
 |
50146-LGC6-E00 | RR. STAY L FLOOR PANEL | $29.07 | 10 |
 |
50149-AGJ5-E00 | STAY, SEAT CATCH | $112.29 | 7 |
 |
50149-LGC6-E00 | STAY SEAT CATCH | $135.48 | 12 |
 |
50150-AGJ5-E00-HJA | BODY ASSY. RR FRAME | $1463.92 | 3 |
 |
50150-AGJ5-E00-J2A | BODY ASSY. RR FRAME | $1463.92 | 1 |
 |
50150-KED9-900 | HOOK R CARRIER | $41.97 | 27 |
 |
50150-LGC6-E00 | BODY ASSY RR FRAME | $830.66 | 12 |
 |
50151-KED9-900 | HOOK L CARRIER | $41.97 | 27 |
 |
50151-KKC4-900 | HOOK CARRIER | $29.52 | 7 |
 |
50152-KED9-900 | BRKT MAIN SWITCH | $36.51 | 27 |
 |
50153-KKE3-900 | RUBBER ECU | $5.22 | 24 |
 |
50153-LCD1-305 | BRACKET A RR CUSHION | $29.67 | 24 |
 |
50153-LDF2-900 | RUBBER SOLENOID VALVE | $8.28 | 22 |
 |
50154-BAC8-E00 | COLLAR | $7.17 | 6 |
 |
50154-KKE3-900 | COLLAR ECU | $7.53 | 26 |
 |
50154-KKE5-700 | STAY RR CARRIER | $89.82 | 6 |
 |
50154-LBA2-E00 | STAY RR CARRIER | $116.82 | 38 |
 |
50154-LCD1-305 | BRACKET B RR CUSHION | $9.57 | 24 |
 |
50154-LDF2-900 | COLLAR | $7.17 | 16 |
 |
50157-KKE5-E00 | PLATE A CROSS | $47.10 | 6 |
 |
50158-AKB8-E01 | BRACKET CARRIER | Ask about this part → | 2 |
 |
50158-BAA7-E00 | STAY SENSOR T-MAP | Ask about this part → | 6 |
 |
50159-ABD2-C00 | "STAY, REG REC" | $17.64 | 13 |
 |
50159-KED9-900 | RUBBER BATTARY STOP | $10.50 | 27 |
 |
5015A-LEE8-900 | STAY PROTECTOR ASSY | $107.22 | 58 |
 |
5015A-LKM8-700 | STAY PROTECTOR ASSY | $148.80 | 71 |
 |
5015A-LKM8-F20 | STAY， PROTECTOR ASSY. | $108.39 | 91 |
 |
50160-LEH2-BA0 | "STAY, FUEL PUMP" | Ask about this part → | 5 |
 |
50162-LCA4-E00 | STAY COIL & REG | $31.56 | 53 |
 |
50162-LLB1-E00 | BRKT COIL & REG | $36.51 | 19 |
 |
50165-LHA7-900 | BRACKET SHIFT | $77.16 | 25 |
 |
50166-AHH8-M00 | BRKT START MAG SW | $9.51 | 8 |
Common questions
How do I know a frame & footrest part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO frame & footrest parts?
Yes — all 1,421 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
