KYMCO transmission & drive part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
2343A-KKD5-C00 | SHAFT FINAL | $245.28 | 16 |
 |
2343A-KNBN-C00 | SHAFT FINAL | $139.83 | 83 |
 |
2343A-KUDU-W00 | SHAFT FINAL | $94.98 | 35 |
 |
2343A-LCD2-C00 | SHAFT FINAL | $76.11 | 3 |
 |
2343A-LEJ2-E10 | SHAFT FINAL | $117.78 | 9 |
 |
2343A-LFB5-C00 | SHAFT FINAL | $105.66 | 36 |
 |
2343A-LHB3-C00 | SHAFT FINAL | $143.13 | 10 |
 |
23440-LCD9-E00 | GEAR ASSY FORWARD | $142.95 | 24 |
 |
23440-PRB3-910 | GEAR ASSY FORWARD (37T) | $140.34 | 8 |
 |
23440-PWA1-E00 | GEAR ASSY FORWARD (39T) | $173.49 | 49 |
 |
23441-4K39-001 | GEAR M-2 | $81.48 | 10 |
 |
23441-ALE8-E00 | SHAFT FINAL DRIVEN REAR | $200.04 | 53 |
 |
23441-KED9-900 | GEAR M-2 | $49.62 | 27 |
 |
23441-KKAK-900 | GEAR M-2 | $87.45 | 2 |
 |
23441-KKE5-E00 | SHAFT A COUNTER | $252.30 | 6 |
 |
23441-LBA7-900 | GEAR FORWARD | $149.43 | 91 |
 |
23441-LBA8-C10 | CARBURETOR ASSY | $35.10 | 12 |
 |
23441-LCA4-E00 | GEAR FORWARD | $115.80 | 53 |
 |
23441-LDB1-700 | GEAR FORWARD | $139.29 | 53 |
 |
23441-LLB1-900 | GEAR FORWARD | $111.06 | 19 |
 |
23441-PTA3-E00 | GEAR FORWARD | $149.43 | 137 |
 |
23441-PWB1-900 | SHAFT FINAL DRIVEN REAR | $155.58 | 92 |
 |
23442-KED9-900 | COLLAR 25*8 | $20.76 | 27 |
 |
23450-KKE5-E00 | SHAFT COMP COUNTER B (17T/26T) | $377.79 | 6 |
 |
23450-LDB5-E00 | GEAR COMP BACKWARD 2ST DRIVEN | $136.26 | 365 |
 |
23450-PRB3-900 | GEAR COMP BACKWARD (61T) | $165.90 | 8 |
 |
23450-ZVA6-M00 | GEAR COMP BACKWARD 2ND DRIVEN 34T | $198.72 | 36 |
 |
23451-4K39-901 | GEAR C-2 (32T) | $110.82 | 10 |
 |
23451-KED9-900 | GEAR C-2 | $103.02 | 27 |
 |
23451-KKAK-900 | GEAR C2 | $109.50 | 2 |
 |
23451-LBA7-900 | GEAR BACKWARD | $146.67 | 137 |
 |
23451-LBA8-C10 | GEAR C-2 | $38.94 | 12 |
 |
23451-LCD9-E00 | GEAR COMP BACKWARD (61T) | $142.53 | 49 |
 |
23451-LDB1-700 | GEAR BACKWARD | $139.29 | 53 |
 |
23451-LLB1-900 | GEAR BACKWARD | $113.34 | 72 |
 |
23451-PRB2-M00 | GEAR BACKWARD DRIVEN 32T | $278.22 | 53 |
 |
23451-PWB1-900 | GEAR, BACKWARD DRIVEN 32T | $161.43 | 92 |
 |
23452-KED9-900 | COLLAR 21.8*9.5 | $37.29 | 27 |
 |
2345A-LDB5-E00 | GEAR COMP BACKWARD | $221.37 | 401 |
 |
23461-4K39-001 | GEAR M-3 (20T) | $91.08 | 12 |
 |
23461-KED9-900 | GEAR M-3 | $100.26 | 27 |
 |
23461-LBA8-C10 | GEAR M-3 | $40.17 | 12 |
 |
23462-KED9-900 | COLLAR SPLINE 22*8 | $30.39 | 13 |
 |
23462-KED9-910 | COLLAR SPLINE 25*8 | $36.51 | 14 |
 |
23471-4K39-001 | GEAR C-3 (28T) | $130.32 | 12 |
 |
23471-KED9-900 | GEAR C-3 | $103.02 | 27 |
 |
23471-LBA8-C10 | CARBURETOR ASSY | $42.30 | 12 |
 |
23471-LCD9-E00 | SHIFT REVERSE & LOWER | $102.12 | 24 |
 |
23471-LCD9-E01 | SHIFT REVERSE & LOWER | $102.12 | 45 |
 |
23471-LDB5-E00 | SHIFT FORWARD & LOWER | $96.69 | 401 |
Common questions
How do I know a transmission & drive part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO transmission & drive parts?
Yes — all 1,497 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
