KYMCO transmission & drive part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
23471-PRB2-M00 | SHIFT FORWARD & LOWER | $212.70 | 53 |
 |
23471-PWB1-900 | SHIFT FORWARD&LOW | $126.42 | 92 |
 |
23472-LBA7-900 | COLLAR 20*25*11 | $20.28 | 137 |
 |
23472-LLB1-900 | COLLAR 15X20X11 | $16.14 | 125 |
 |
23472-PWB1-900 | RING 25 INNER | $31.17 | 145 |
 |
23473-LBA7-900 | COLLAR 20*22*11 | $19.35 | 137 |
 |
23473-LDB5-E00 | COLLAR 20X17X14 | $23.40 | 401 |
 |
23473-PWB1-900 | COLLAR 20X30X9.5 | $32.10 | 145 |
 |
23481-4K39-001 | GEAR M-4 (23T) | $124.38 | 12 |
 |
23481-KED9-900 | GEAR M-4 | $80.43 | 27 |
 |
23481-LBA7-900 | SHIFT MAIN | $137.82 | 137 |
 |
23481-LBA8-C10 | GEAR M-4 | $39.72 | 12 |
 |
23481-LCA4-E00 | SHIFT MAIN | $132.99 | 106 |
 |
23481-LCD9-E00 | SHIFT FORWARD | $135.24 | 12 |
 |
23481-LCD9-E01 | SHIFT FORWARD | $135.24 | 24 |
 |
23481-LDB5-E00 | SHIFT BACKWARD | $133.77 | 401 |
 |
23481-LLB1-900 | SHIFT MAIN | $109.68 | 19 |
 |
23481-PRB2-M00 | SHIFT BACKWARD | $171.84 | 53 |
 |
23481-PWA1-E00 | SHIFT FORWARD | $135.24 | 57 |
 |
23481-PWB1-900 | SHIFT BACKWARD | $114.66 | 92 |
 |
23491-4K39-001 | GEAR C-4 (26T) | $102.78 | 12 |
 |
23491-ALB1-900 | GEAR C-4 | $174.63 | 9 |
 |
23491-KED9-900 | GEAR C-4 | $163.26 | 27 |
 |
23491-LCA7-C10 | GEAR C-4 | $24.66 | 12 |
 |
23492-ALB1-900 | SPRING B SHIFT | $15.06 | 9 |
 |
23493-ALB1-900 | COLLAR SHIFT LIFTER | $125.25 | 9 |
 |
23494-ALB1-900 | SPRING A SHIFT | $47.31 | 9 |
 |
23495-KED9-900 | COLLAR 22*13 | $20.76 | 27 |
 |
23500-LDB5-E00 | GEAR COMP LOWER DRIVEN 35T | $139.29 | 401 |
 |
23501-KED9-900 | GEAR M-5 | $87.24 | 27 |
 |
23501-KKA8-900 | MAIN SHAFT FIFTH 26T | $106.08 | 12 |
 |
23510-AAA6-900 | GEAR FORWARD DRIVEN 29T | $249.24 | 11 |
 |
23510-ALE8-E00 | GEAR FORWARD DRIVEN 18T | $197.79 | 53 |
 |
23510-LDB5-900 | GEAR FORWARD DRIVEN 27T | $148.68 | 277 |
 |
23510-LDB5-E00 | GEAR FORWARD DRIVEN 28T | $131.16 | 113 |
 |
23510-PWB1-900 | GEAR, FORWARD DRIVEN 19T | $119.58 | 92 |
 |
23511-KED9-900 | GEAR C-5 | $87.24 | 27 |
 |
23511-KKA8-900 | GEAR C-5 (24T) | $118.41 | 12 |
 |
23511-LCD9-E00 | SHAFT COMP COUNTER | $158.73 | 24 |
 |
23511-PRB2-M00 | GEAR FORWARD DRIVEN 32T | $312.51 | 53 |
 |
23511-PTA1-900 | GEAR, FORWARD DRIVEN 33T | $276.09 | 59 |
 |
23511-PWB1-900 | GEAR FORWARD DRIVEN 33T | $173.58 | 33 |
 |
23512-KED9-900 | COLLAR SPLINE 22*14 | $31.89 | 27 |
 |
23512-PRB2-M00 | GEAR LOWER DRIVEN 40T | $327.57 | 53 |
 |
23512-PWB1-900 | GEAR LOWER DRIVEN 40T | $166.17 | 92 |
 |
23515-KED9-900 | COLLAR OIL SEAL COUNTER | $37.14 | 27 |
 |
23518-ALE8-E00 | BEVEL GEAR DRIVE | $268.47 | 53 |
 |
23518-LCD9-E0A | GEAR BEVEL DRIVE | $114.30 | 49 |
 |
23518-LKM5-E00 | BEVEL GEAR DRIVE | $252.72 | 401 |
 |
23518-PRB3-900 | GEAR BEVEL DRIVE | $166.14 | 8 |
Common questions
How do I know a transmission & drive part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO transmission & drive parts?
Yes — all 1,497 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
