KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90341-PWB1-900 | SHIM DRIVEN BEVEL GEAR K (1.075~1.125) | $6.24 | 2 |
 |
90342-LCD9-E00 | SHIM DRIVEN BEVEL GEAR L (1.125~1.175) | $8.01 | 57 |
 |
90342-PWB1-900 | SHIM DRIVEN BEVEL GEAR L (1.125~1.175) | $12.09 | 145 |
 |
90343-PWB1-900 | SHIM DRIVEN BEVEL GEAR M (1.175~1.225) | $6.24 | 2 |
 |
90344-PWB1-900 | SHIM DRIVEN BEVEL GEAR N (1.225~1.275) | $6.24 | 2 |
 |
90381-GEZ5-C00 | SCREW SPECIAL 6*17 | $4.20 | 65 |
 |
90381-GEZ5-C01 | SCREW SPECIAL 6*17 | $4.65 | 22 |
 |
90381-GZE5-001 | SCREW SPECIAL 6*17 | $4.59 | 172 |
 |
90401-KED9-900 | CLIP MAIN SHAFT BALL BRG | $17.13 | 27 |
 |
90401-KKE5-E00 | WASHER THRUST 22*45*1.5 | $16.77 | 6 |
 |
90401-KKJ9-001 | WASHER THRUST 14*28*2 | $5.67 | 873 |
 |
90401-KKJ9-C00 | WASHER THRUST 14*28*2 | $11.19 | 15 |
 |
90401-LCA7-C10 | WASHER 17.4MM | $1.32 | 12 |
 |
90401-LEA7-E00 | WASHER THRUST 14*28*2 | $16.68 | 48 |
 |
90401-PTA1-900 | WASHER.THRUST 14MM | $5.94 | 18 |
 |
90402-LBA2-E00 | THRUST WASHER 46*80*1.5 | $32.73 | 25 |
 |
90402-LEA7-950 | WASHER THRUST 14*28*2 | $51.81 | 160 |
 |
90402-LEA7-E00 | THRUST WASHER 36X60X3 | $38.52 | 48 |
 |
90403-AKB8-E00 | WASHER 28.5X40X1.5 | Ask about this part → | 2 |
 |
90403-GFY6-901 | WASHER THRUST 22. 2*31*2.5 | $6.06 | 22 |
 |
90403-GFY6-C00 | WASHER THRUST 22.2*31*2.5 | $4.65 | 32 |
 |
90403-KED9-900 | WASHER WAVE 10MM | $5.67 | 293 |
 |
90403-KGN7-671 | WASHER THRUST 28X44X1.5 | $14.73 | 94 |
 |
90403-KKE5-E00 | WASHER 25.2*37*1.5 | $16.77 | 6 |
 |
90403-KUDU-900 | WASHER THRUST 22.2X39X2.5 | $12.45 | 158 |
 |
90403-KUDU-C00 | WASHER THRUST 22.2*39*2.5 | $9.39 | 50 |
 |
90403-LBA2-E00 | WASHER 68*81*4 | $31.11 | 25 |
 |
90403-LCD9-E00 | WASHER THRUST 20MM | $6.93 | 24 |
 |
90403-LEA2-900 | WASHER THRUST 22.5X311.5 | $11.31 | 16 |
 |
90403-LEA3-900 | WASHER THRUST 16.2*30*1.5 | $14.73 | 16 |
 |
90403-LEA7-E00 | THRUST WASHER 20.2X35X2.35 | $19.26 | 48 |
 |
90403-LFA5-900 | WASHER WAVE SPRING | $23.70 | 92 |
 |
90403-LGC6-E00 | WAVE WASHER 25MM | $3.66 | 19 |
 |
90403-LKL5-E30 | WASHER | $4.65 | 12 |
 |
90403-LLB1-900 | WASHER THRUST 22.2*39*2.5 | $14.31 | 66 |
 |
90403-PWB1-900 | WASHER WAVE SPRING | $23.70 | 33 |
 |
90404-ALH3-900 | WASHER WAVE | $22.23 | 10 |
 |
90404-KKE5-E00 | WASHER 16*28*5 | $16.77 | 6 |
 |
90404-PWA1-E00 | WASHER THRUST 25MM | $14.70 | 57 |
 |
90405-KED9-900 | WASHER 10*25*4 | $4.92 | 33 |
 |
90405-LDB5-E00 | COLLAR CLUTCH | $42.84 | 241 |
 |
90405-LGC6-E00 | COLLER CLUTCH | Ask about this part → | 2 |
 |
90405-LKM5-E00 | COLLAR CLUTCH | $83.13 | 160 |
 |
90406-KED9-900 | WASHER 32*25*3 | $4.92 | 27 |
 |
90406-KKE5-E00 | WASHER THRUST 22*45*1.0 | $9.84 | 6 |
 |
90406-LDB5-E00 | WASHER 25*33*4 | $13.17 | 401 |
 |
90406-LGC6-E00 | WASHER 25X38X2 | Ask about this part → | 2 |
 |
90407-KAM1-001 | SEALING WASHER B OIL PIPE JOIN | $1.86 | 139 |
 |
90407-KKE5-E00 | WASHER 16*36*5 | $31.17 | 6 |
 |
90407-LBA2-E00 | SEALING WASHER OIL PIPE | $5.67 | 426 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
