KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90305-KNCN-900 | NUT SPECIAL 12MM | $26.46 | 16 |
 |
90305-LBA2-C00 | "NUT, CLIP 6MM" | $4.59 | 15 |
 |
90305-LBA2-E00 | NUT CLIP 6MM | $3.78 | 118 |
 |
90305-LBD4-900 | NUT U 14MM | $21.21 | 82 |
 |
90305-LBD4-C00 | NUT U FLANGE 14MM | $18.87 | 3 |
 |
90305-LKL5-E30 | NUT U FLANGE 16MM(K) | $15.06 | 5 |
 |
90305-LKL5-E31 | NUT U FLANGE 16MM(K) | $8.19 | 7 |
 |
90305-MAA1-004 | U NUT FLANGE 14MM | $5.85 | 384 |
 |
90305-MAA1-C01 | NUT U FLANGE 14MM | $22.08 | 12 |
 |
90305-PUA3-B51 | NUT U 16MM(C) | $14.94 | 151 |
 |
90306-GLW0-90A | NUT U FLANGE 12MM(C) | $17.55 | 549 |
 |
90306-KLF0-004 | NUT FLANGE 12MM | $7.89 | 11 |
 |
90306-KLF0-004-SY | NUT FLANGE 12MM | $13.95 | 470 |
 |
90306-KLF0-C00 | NUT FLANGE 12MM | $12.36 | 108 |
 |
90306-KLF0-C02 | NUT FLANGE 12MM(B) | $15.06 | 52 |
 |
90306-LBA2-900 | NUT U 20MM | $68.76 | 50 |
 |
90306-LCD9-E00 | NUT 18MM | $20.88 | 57 |
 |
90306-LFE2-900 | NUT FLANGE 12MM | $15.63 | 74 |
 |
90306-LFE2-910 | NUT FLANGE 12MM | $6.00 | 7 |
 |
90306-LKL5-E30 | NUT U FLANGE 12MM | $4.92 | 5 |
 |
90306-LKL5-E31 | NUT U FLANGE 12MM(K) | $18.96 | 52 |
 |
90307-GFJ6-004 | WASHER LOCK 6MM | $4.92 | 92 |
 |
90309-4H28-73A | NUT FLANGE 8MM | $6.06 | 119 |
 |
90309-GLW0-90A | NUT U FLANGE 8MM | $6.06 | 389 |
 |
90309-KLF0-004 | NUT FLANGE 8MM | $21.93 | 381 |
 |
90309-KLF0-C00 | NUT FLANGE 8MM(C) | $7.53 | 21 |
 |
90309-LBE8-900 | U NUT 8MM | $6.54 | 42 |
 |
90309-LKL5-E30 | NUT U FLANGE 8MM | $3.60 | 5 |
 |
90309-LKL5-E31 | NUT U FLANGE 8MM | $8.97 | 7 |
 |
90309-PUA3-B50 | NTU FLANGE 8MM | $3.93 | 62 |
 |
90311-LCD9-E00 | SHIM FINAL BEVEL GEAR A (0.575~0.625) | $9.18 | 57 |
 |
90311-LDB5-E00 | SHIM DRIVE BEVEL GEAR A (0.575~0.625) | $1.08 | 380 |
 |
90311-PWB1-900 | SHIM DRIVEN BEVEL GEAR A (0.575~0.625) | $6.24 | 21 |
 |
90312-AHG1-E00 | IRON BUSHING | Ask about this part → | 2 |
 |
90312-GLF0-001 | COLLAR BODY COVER | $1.86 | 63 |
 |
90312-LCD3-E01 | COLLAR VISOR | $9.39 | 92 |
 |
90312-LCD9-E00 | SHIM FINAL BEVEL GEAR B (0.625~0.675) | $9.18 | 57 |
 |
90312-LDB5-E00 | SHIM DRIVE BEVEL GEAR B (0.625~0.675) | $11.31 | 371 |
 |
90312-LEE8-E00 | COLLAR LATCH | $10.14 | 215 |
 |
90312-LLJ3-C00 | COLLAR WIND SCREEN | $3.60 | 15 |
 |
90312-LLJ3-E00 | COLLAR WIND SCREEN | $12.12 | 45 |
 |
90312-LLJ3-E01 | COLLAR WIND SCREEN | $7.53 | 86 |
 |
90312-PWB1-900 | SHIM DRIVEN BEVEL GEAR B (0.625~0.675) | $6.24 | 21 |
 |
90313-LCD9-E00 | SHIM FINAL BEVEL GEAR C (0.675~0.725) | $9.18 | 57 |
 |
90313-LDB5-E00 | SHIM DRIVE BEVEL GEAR C (0.675~0.725) | $11.31 | 401 |
 |
90313-PWB1-900 | SHIM DRIVEN BEVEL GEAR C (0.675~0.725) | $6.24 | 21 |
 |
90314-LCD9-E00 | SHIM FINAL BEVEL GEAR D (0.725~0.775) | $9.18 | 57 |
 |
90314-LDB5-E00 | SHIM DRIVE BEVEL GEAR D (0.725~0.775) | $11.31 | 298 |
 |
90314-PWB1-900 | SHIM DRIVEN BEVEL GEAR D (0.725~0.775) | $6.24 | 21 |
 |
90315-LCD9-E00 | SHIM FINAL BEVEL GEAR E (0.775~0.825) | $9.18 | 57 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
