KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90302-LBF2-900 | BOLT-WASH M5X10 | $5.67 | 239 |
 |
90302-LKB9-900 | NUT SPRING 5MM | $11.79 | 20 |
 |
90302-LKB9-910 | NUT SPRING 5MM | $11.79 | 10 |
 |
90302-LKB9-C00 | NUT SPRING 5MM | $7.02 | 13 |
 |
90302-LLB1-BA1 | BOLT-WASH 5X12 | $0.66 | 5 |
 |
90302-LLB1-C01 | BOLT-WASH 5*12 | $1.32 | 37 |
 |
90302-LLB1-E00 | BOLT-WASH 5X12 | $2.61 | 851 |
 |
90302-LLB1-E02 | BOLT-WASH 5X12(KG) | $1.65 | 7 |
 |
90302-PUA3-B51 | BOLT-WASH 5*12 | $4.65 | 136 |
 |
90302-PWA1-900 | BOLT-WASH 5*16 | $4.92 | 457 |
 |
90302-PWA5-900 | BOLT-WASH 5*12 | $4.92 | 164 |
 |
90302-PWB1-900 | BOLT-WASH 5*22 | $4.92 | 268 |
 |
90302-SA4-0040 | NUT SPRING 4MM | $4.26 | 756 |
 |
90302-SDA4-BA0 | NUT SPRING 4MM | $2.61 | 5 |
 |
90302-SDA4-C01 | NUT SPRING 4MM | $0.99 | 227 |
 |
90304-4H38-001 | NUT HEX CAP 6MM | $6.78 | 416 |
 |
90304-4H38-C00 | NUT HEX CAP 6MM | $12.48 | 133 |
 |
90304-AKB8-E00 | NUT STRG STEM | $43.62 | 2 |
 |
90304-GHE8-004 | NUT U 10MM | $12.84 | 530 |
 |
90304-GHE8-004-SW | NUT U FLANGE 10MM | $8.19 | 90 |
 |
90304-GHE8-004-SY | NUT U 10MM | $8.85 | 149 |
 |
90304-GHE8-C00 | NUT U 10MM (C) | $18.33 | 117 |
 |
90304-GHE8-C01 | NUT U 10MM(C) | $21.45 | 92 |
 |
90304-GLW0-90A | NUT U FLANGE 10MM | $9.39 | 940 |
 |
90304-HCB3-77A | NUT SPECIAL 6MM | $7.17 | 45 |
 |
90304-KHBH-900 | NUT STRG STEM | $38.94 | 10 |
 |
90304-KKAK-900 | NUT STRG STEM | $48.24 | 41 |
 |
90304-KKE5-E00 | NUT. STRG. STEM | $53.43 | 56 |
 |
90304-LBD4-900 | NUT U FLANGE 10MM | $7.53 | 265 |
 |
90304-LBD4-C00 | NUT U FLANGE 10MM | $6.54 | 3 |
 |
90304-LBD4-C01 | NUT U FLANGE 10MM | $3.60 | 12 |
 |
90304-LEA1-900 | NUT U FLANGE 10MM | $11.31 | 68 |
 |
90304-LEA1-C00 | NUT U FLANGE 10MM (G) | $6.54 | 11 |
 |
90304-LEA1-C01 | NUT U FLANGE 10MM (G) | $11.67 | 28 |
 |
90304-LGC6-E00 | NUT M10X1.25(C) | $2.82 | 19 |
 |
90304-PUA3-B50 | NUT U 10MM(C) | $13.62 | 30 |
 |
90304-ZZA6-E00 | NUT CAP 6MM | Ask about this part → | 9 |
 |
90305-GHE8-004 | NUT U 14MM | $29.10 | 304 |
 |
90305-GHK8-001 | NUT CLIP 6MM | $4.92 | 897 |
 |
90305-GHK8-C00 | NUT U 16MM(C) | $4.20 | 99 |
 |
90305-GHK8-C01 | NUT CLIP 6MM | $2.61 | 43 |
 |
90305-KFW6-900 | NUT U FLANGE 16MM (B) | $38.64 | 161 |
 |
90305-KFW6-91A | NUT U 16MM | $31.17 | 60 |
 |
90305-KFW6-C00 | NUT U FLANGE 16MM(C) | $11.73 | 37 |
 |
90305-KKAK-900 | NUT U 16MM | $22.38 | 83 |
 |
90305-KKAK-C00 | NUT U FLANGE 16MM (CR) | $21.60 | 15 |
 |
90305-KNBN-90A | 0 | $16.11 | 16 |
 |
90305-KNBN-90B | NUT U 16MM | $24.99 | 247 |
 |
90305-KNBN-C00 | NUT U 16MM(C) | $14.94 | 4 |
 |
90305-KNBN-C03 | NUT U 16MM(K) | $22.08 | 8 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
