KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90114-LGE5-E01 | BOLT FLANGE 6X30.5 ABS | $27.39 | 15 |
 |
90115-1G47-001 | SCREW HNDL LEVER PIVOT | $4.92 | 9 |
 |
90115-GLE0-001 | BOLT HNDL LEVER PIVOT | $4.92 | 211 |
 |
90115-GLE0-C00 | BOLT HNDL LEVER PIVOT | $13.77 | 51 |
 |
90115-KED9-900 | BOLT CHANGE PIVOT | $15.45 | 27 |
 |
90115-LKB9-900 | BOLT FLANGE SH 6*32 | $8.82 | 18 |
 |
90115-LLB1-810 | BOLT HANDLE LEVER PIROT | Ask about this part → | 238 |
 |
90115-LLB1-900 | BOLT HNDL LEVER PIVOT | $8.49 | 3 |
 |
90115-LLB1-E01 | BOLT HNDL LEVER PIVOT | $5.22 | 13 |
 |
90116-3C83-72A | BOLT | $5.22 | 181 |
 |
90116-GGS7-C00 | SCREW P/BRK LEVER PIVOT | $1.65 | 33 |
 |
90116-KEC8-C00 | SOCKET BOIT | $5.58 | 7 |
 |
90116-KED9-900 | SCREW PAN 6X24(, ) | $6.39 | 381 |
 |
90116-KHD8-900 | BOLT | $17.82 | 161 |
 |
90116-LDC8-E10 | BOLT | $4.92 | 41 |
 |
90117-KED9-950 | BOLT FLANGER 10X265 | $25.83 | 96 |
 |
90118-KED9-900 | BOLT FLANGE 10*85 | $13.35 | 27 |
 |
90118-PVA2-900 | BOLT FLANGE 8*38 | $7.89 | 190 |
 |
90120-ALK1-C00 | SOCKET BOLT SPECIAL 6*22 | $10.14 | 4 |
 |
90120-GAR1-C00 | SOCKET BOLT SPECIAL 6*28 | $12.84 | 10 |
 |
90120-GAR1-J00 | SOCKET BOLT SPECIAL 6*28 | $9.06 | 66 |
 |
90120-KEC2-C00 | SOCKET BOLT SPECIAL 6*13 | $14.07 | 10 |
 |
90120-KGAG-520 | SOCKET BOT SPECIAL 6X23 | $7.53 | 25 |
 |
90120-LEJ3-C00 | SOCKET BOLT SPECIAL 6*22 | $10.14 | 8 |
 |
90120-LFC8-C00 | SOCKET BOLT SPECIAL 6*20 | $4.26 | 39 |
 |
90120-PVA2-900 | BOLT SOCKET SPECIAL 6X23 | $6.15 | 162 |
 |
90121-GFY6-901 | COLLAR DISTANCE | $7.53 | 189 |
 |
90121-GFY6-C00 | COLLAR DISTANCE | $22.62 | 84 |
 |
90121-KBE2-C01 | BOLT RR FORK PIVOT M12*255 | $77.52 | 120 |
 |
90121-KED9-900 | BOLT RR FORK PIVOT M14*295MM | $25.95 | 27 |
 |
90121-KHE7-E00 | COLLAR DISTANCE | $5.67 | 66 |
 |
90121-LBA7-900 | BOLT RR FORK PIVOT M14*280MM | $37.95 | 309 |
 |
90121-LBE8-900 | BOLT RR FORK PIVOT M12/280MM | $53.58 | 10 |
 |
90121-LCD9-E00 | FORK PIVOT BOLT RH | $40.53 | 82 |
 |
90121-LEC8-E00 | BOLT RR FORK (PIVOT) M12*288MM | $56.67 | 2 |
 |
90121-LGC6-E00 | BOLT FLANGE 10X50 | $11.19 | 12 |
 |
90121-LKL5-E30 | BOLT RR FORK PIVOT | $50.76 | 5 |
 |
90121-LKL5-E31 | BOLT RR FORK PIVOT | $97.38 | 7 |
 |
90122-AGJ5-E00 | BOLT FLANGE8*20 | $5.19 | 7 |
 |
90122-GCS3-001 | WASHER 12MM | $10.14 | 93 |
 |
90122-GCS3-C00 | WASHER 12MM | $4.92 | 10 |
 |
90122-KEBE-900 | BOLT FLANGE 8*32 | $9.39 | 521 |
 |
90122-KGD4-C11 | BOLT FLANGE 8*25(C) | $4.92 | 5 |
 |
90122-KGD4-C12 | BOLT FLANGE 8*25(C) | $8.97 | 7 |
 |
90122-KHC7-C01 | BOLT FLANGE 8*38 | $5.58 | 37 |
 |
90122-KKE5-E00 | BOLT FLANGE 8*35 | $22.26 | 6 |
 |
90122-LBA2-E00 | BOLT FLANGE 8X38 | $14.31 | 48 |
 |
90122-LCD9-E00 | FORK PIVOT BOLT LH | $43.62 | 82 |
 |
90122-LEA7-C01 | BOLT FLANGE 10X42(KG) | $17.61 | 15 |
 |
90122-LEA7-E00 | BOLT FLANGE 10X42 | $25.65 | 53 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
