KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90122-LKA8-E00 | BOLT FLANGE 10x20 | $19.26 | 278 |
 |
90122-LKF5-E00 | BOLT FLANGE 10*58 | $24.99 | 20 |
 |
90122-LKL5-E30 | BOLT FLANGE 8*25 | $2.61 | 5 |
 |
90122-LKL5-E31 | BOLT FLANGE 8*25 | $8.97 | 7 |
 |
90122-LLB1-800 | BOLT FLANGE 8*28 | $7.53 | 231 |
 |
90123-KKE5-E00 | BOLT FLANGE 8*45 | $17.97 | 6 |
 |
90123-LCD9-E00 | FORK PIVOT NUT LOCK | $33.39 | 82 |
 |
90123-LGC6-E00 | BOLT FLANGE 10X95 | $20.43 | 19 |
 |
90124-LDB5-E00 | WASHER 41X22X1.2 | $6.09 | 25 |
 |
90125-AGJ5-E00 | BOLT, FLANGE 10X120.5(G) | $29.16 | 7 |
 |
90125-AKB8-E00 | BOLT FLANGE 10X140 | Ask about this part → | 2 |
 |
90125-KED9-900 | BOLT SPECIAL FLANGE 8*20 | $8.67 | 27 |
 |
90125-LGC6-E00 | BOLT FLANGE 10X130 | $24.66 | 10 |
 |
90127-KED9-900 | BOLT RR BRK STOPPER | $11.79 | 27 |
 |
90127-LBE8-900 | BOLT RR BRK PANEL STOPPER | $22.23 | 10 |
 |
90127-LKL5-E30 | BOLT RR BRK STP ARM | $8.85 | 5 |
 |
90127-LKL5-E31 | BOLT RR BRK STP ARM | $8.85 | 7 |
 |
90128-KEC8-C00 | BOLT HLANGE | $6.24 | 7 |
 |
90131-GLW0-911 | BOLT FLANGE 8*35 | $9.39 | 188 |
 |
90131-GLW0-C00 | BOLT FLANGE 8*35 | $9.18 | 96 |
 |
90131-GLW0-C02 | BOLT FLANGE 8*35 | $7.50 | 59 |
 |
90131-KEBE-900 | BOLT FLANGE 8*24 | $16.08 | 133 |
 |
90131-KFAF-900 | BOLT FLANGE 8*42 | $17.82 | 54 |
 |
90131-KUCU-900 | BOLT FLANGE 8*45 | $12.12 | 6 |
 |
90131-LDB2-E00 | BOLT FLANGE 8X45 | $13.11 | 50 |
 |
90131-LEA5-E00 | BOLT FLANGE 8*42 | $16.38 | 28 |
 |
90131-LEB1-900 | BOLT FLANGE 8X35 | $8.28 | 54 |
 |
90131-LFA5-E00 | BOLT FLANGE 8X22 | $5.07 | 62 |
 |
90131-LFB5-900 | BOLT FLANGE 8X55 | $22.86 | 58 |
 |
90131-LFG2-E00 | BOLT FLANGE 8X55 | $18.24 | 25 |
 |
90131-PRB3-900 | BOLT FLANGE 8X20 | $22.50 | 339 |
 |
90133-KED9-950 | BOLT RR BRK STOPPER ARM | $7.53 | 27 |
 |
90133-LDB5-E00 | WASHER BOLT SEAT | $4.53 | 401 |
 |
90133-LLB1-900 | WASHER BOLT SEAT | $2.61 | 328 |
 |
90136-KED9-900 | BOLT CRANKCASE M8 MAIN | $14.46 | 27 |
 |
90145-9A61-C00 | OIL BOLT 10*22 | $7.89 | 119 |
 |
90145-9A61-C01 | OIL BOLT 10*22 | $82.38 | 24 |
 |
90145-LBA2-E00 | OIL BOLT 10*33 | $29.10 | 110 |
 |
90145-LEA3-E00 | OIL BOLT 10*22 | $22.86 | 1497 |
 |
90145-LEA3-E01 | OIL BOLT 10*22 | $10.38 | 7 |
 |
90145-LFH1-E00 | OIL BOLT 10x22 | $29.52 | 87 |
 |
90145-MKS9-61A | OIL BOLT 10X22 | $9.06 | 71 |
 |
90145-MKS9-C00 | OIL BOLT 10*22 | $7.53 | 30 |
 |
90150-4C63-77A | SCREW PAN 5*10 | $6.06 | 42 |
 |
90164-0H28-900 | SCREW FLAT U LOCK 6*12 | $4.92 | 350 |
 |
90164-ADG8-E00 | BOLT M5X12 | $5.22 | 51 |
 |
90164-KGBG-900 | SCREW SPECIAL 6MM | $4.92 | 106 |
 |
90164-KGBG-C00 | SCREW SPECIAL 6MM | $4.92 | 12 |
 |
90164-MDR4-901 | SCREW SPECIAL 6MM | $7.53 | 36 |
 |
90185-PWB1-900 | SOCKET BOLT 8x45 | $17.82 | 160 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
