KYMCO bolts & hardware part numbers and diagrams
| Part number | Name | Price | Fits models | |
|---|---|---|---|---|
 |
90241-KKE5-E00 | NUT LOCK 30MM | $108.30 | 6 |
 |
90242-KKE5-E00 | NUT LOCK 22M | $43.77 | 6 |
 |
90242-LCD9-E00 | NUT LOCK 65MM | $20.76 | 57 |
 |
90242-LDB5-E00 | NUT LOCK 74MM | $33.00 | 380 |
 |
90242-LEE8-E00 | NUT LOCK 74MM | $91.08 | 39 |
 |
90243-LDB5-E00 | NUT LOCK 85 mm | $47.70 | 401 |
 |
90301-4C73-004 | NUT U 6MM | $4.92 | 70 |
 |
90301-4C73-C01 | NUT U 6MM(C) | $19.89 | 89 |
 |
90301-6C93-001 | NUT FLANGE 6MM | $4.92 | 48 |
 |
90301-6C93-C00 | NUT 6MM OPENSTAY | $8.19 | 3 |
 |
90301-6C93-C01 | NUT 6MM OPENSTAY | $8.97 | 15 |
 |
90301-6D34-671 | NUT FLANGE 6MM | $3.00 | 785 |
 |
90301-6D34-C00 | NUT FLANGE 6MM(C) | $5.37 | 7 |
 |
90301-6D34-C01 | NUT FLANGE 6MM(C) | $5.37 | 45 |
 |
90301-GFY6-901 | NUT (HEX) CAP 8MM(C) | $19.26 | 437 |
 |
90301-GFY6-C01 | NUT (HEX) CAP 8MM | $15.21 | 127 |
 |
90301-KCAC-900 | NUT STRG STEM | $21.99 | 18 |
 |
90301-KED9-900 | SEAL-CAP COOLANT | $11.31 | 27 |
 |
90301-KGBG-900 | NUT CAP 6MM | $10.74 | 250 |
 |
90301-KGBG-C00 | NUT CAP 6MM | $22.92 | 41 |
 |
90301-KGBG-C01 | NUT CAP 6MM | $24.33 | 41 |
 |
90301-KKAK-900 | NUT U 6MM | $10.50 | 27 |
 |
90301-LAC5-671 | NUT FLANGE 6MM | $1.95 | 12 |
 |
90301-LAC5-681 | NUT FLANGE 6MM (KG) | Ask about this part → | 9 |
 |
90301-LBA7-900 | NUT WHEEL M10 | $7.71 | 247 |
 |
90301-LBA8-C10 | NUT STRG STEM | $10.80 | 12 |
 |
90301-LDB5-E00 | NUT WHEEL | $18.24 | 453 |
 |
90301-LEJ2-E10 | NUT FLANGE 6mm | $4.92 | 10 |
 |
90301-LEJ2-E11 | NUT FLANGE 6mm | $4.92 | 4 |
 |
90301-LGN5-E00 | NUT WHEEL | $13.77 | 22 |
 |
90301-LLB1-810 | NUT U 6MM(K) | Ask about this part → | 238 |
 |
90301-PWB1-900 | NUT LUG-M10 (60 DEG) | $16.41 | 92 |
 |
90302-GBR2-000-06 | BOLT WASH 5*16 | $4.92 | 6 |
 |
90302-GBR2-001 | BOLT-WASH 5x16 | $3.99 | 653 |
 |
90302-GBR2-C00 | BOLT-WASH 5*16 | $4.59 | 3 |
 |
90302-GBR2-C01 | BOLT WASHER 5*16 | $1.32 | 10 |
 |
90302-GFY6-901 | BOLT-WASH 5*12 | $3.99 | 871 |
 |
90302-GFY6-940 | BOLT-WASH 5*16 | $1.86 | 1066 |
 |
90302-GFY6-950 | BOLT-WASH 5X16 | $1.65 | 7 |
 |
90302-GFY6-C00 | BOLT-WASH 5*12 | $4.92 | 57 |
 |
90302-GFY6-C10 | BOLT-WASH 5*16 | $5.61 | 48 |
 |
90302-GFY6-C11 | BOLT-WASH 5*16 | $4.65 | 72 |
 |
90302-KEC8-900 | BOLT PAN 5*9 | $9.78 | 92 |
 |
90302-KED5-900 | BOLT PAN 5X11 (G) | $9.78 | 140 |
 |
90302-KFC2-900 | BOLT WASHER 5*25 | $4.92 | 72 |
 |
90302-KKE5-E00 | NUT SPRING 4MM | $5.88 | 6 |
 |
90302-KKE5-E10 | BOLT-WASH M5*10 | $5.88 | 6 |
 |
90302-KNBN-900 | BOLT PAN 5*10 | $4.65 | 207 |
 |
90302-KNBN-C00 | BOLT PAN 5*10 | $4.20 | 37 |
 |
90302-KNBN-C01 | BOLT PAN 5*15.5(K) | $8.97 | 48 |
Common questions
How do I know a bolts & hardware part fits my KYMCO?
Every part lists the exact models it fits. Browse from your model's diagrams, use the VIN lookup, or pin your vehicle and the list badges what fits.
Are these genuine KYMCO bolts & hardware parts?
Yes — all 2,538 parts here are factory KYMCO items with original part numbers, straight from the official catalogs.
