F12 — ECU ASSY
The ECU ASSY diagram contains 35 genuine OEM parts for the KYMCO AK550 ST. Hover a callout on the drawing to highlight the part in the list, click it to open the part, or click the drawing to zoom.
| # | Part | Name | Qty | Price | ||
|---|---|---|---|---|---|---|
| 1 | 31440-AKB8-E00 | MOTOR ASSY ELECTRIC ADJUSTED VISOR | 1 | — | Part details → | |
| 2 | 31441-AKB8-E00 | WIRE WHEEL BOX | 1 | — | Part details → | |
| 3 | 31445-AKB8-E00 | MOTOR UNIT | 1 | — | Part details → | |
| 4 | 31448-AKB8-E00 | CLIP SLIDING BRKT CABLE | 1 | — | Part details → | |
| 5 | 31449-AKB8-E00 | STAY ELECTRIC VISOR MOTOR | 1 | — | Part details → | |
| 6 | 39208-AKB8-E01 | HOLDER M4C ECU | 1 | $9.42 USD | View product → | |
| 7 | 39208-AKC3-EZ5 | HOLDER M4C ECU | 1 | $9.42 USD | View product → | |
| 8 | 39209-AKB8-E00 | STAY ECU | 1 | $38.07 USD | View product → | |
| 9 | 3920A-AKB8-E00 | ECU ASSY | 1 | $455.30 USD | View product → | |
| 10 | 64316-AKB8-E00 | SLIDING SPRING VISOR ASSY | 1 | — | Part details → | |
| 11 | 64319-AKB8-E00 | BRKT FR COVER | 1 | — | Part details → | |
| 12 | 64323-AKB8-E00 | TRACK R SLIDING BRKT | 2 | — | Part details → | |
| 13 | 64331-AKB8-E00 | BRKT CROSS | 1 | — | Part details → | |
| 14 | 64332-AKB8-E00 | SLIDIER | 4 | — | Part details → | |
| 15 | 64333-AKB8-E00 | DAMPING SLIDER | 8 | — | Part details → | |
| 16 | 64334-AKB8-E00 | STAY CABLE ASSY | 1 | — | Part details → | |
| 17 | 64335-AKB8-E00 | STAY CABLE | 1 | — | Part details → | |
| 18 | 64336-AKB8-E00 | BRKT AUTO VISOR | 1 | — | Part details → | |
| 19 | 64338-AKB8-E00 | COLLAR. AUTO VISOR BRKT | 1 | — | Part details → | |
| 20 | 64341-AKB8-E00 | PULLEY CABLE | 1 | — | Part details → | |
| 21 | 64342-AKB8-E00 | COLLAR | 4 | — | Part details → | |
| 22 | 64343-AKB8-E00 | COLLAR | 4 | — | Part details → | |
| 23 | 64355-AKB8-E00 | ARM CABLE FIXED | 1 | — | Part details → | |
| 24 | 64357-AKB8-E00 | COLLAR C | 1 | — | Part details → | |
| 25 | 6435A-AKB8-E00 | CABLE ASSY SLIDING BRKT | 1 | — | Part details → | |
| 26 | 6435B-AKB8-E00 | CABLE ASSY B SLIDING BRKT | 1 | — | Part details → | |
| 27 | 93404-06012-06 | BOLT WASHER 6X12 | 2 | $2.61 USD | View product → | |
| 28 | 93500-05012-0HG | SCREW PAN 5*12 | 1 | $0.99 USD | View product → | |
| 29 | 94001-06080-0SG | NUT HEX 6MM | 2 | $0.27 USD | View product → | |
| 30 | 94050-06060 | NUT FLANGE 6MM | 9 | $4.92 USD | View product → | |
| 31 | 94103-06600 | WASHER PLAIN 6MM | 1 | $1.95 USD | View product → | |
| 32 | 95701-06012-06 | BOLT FLANGE 6X12 | 6 | $1.86 USD | View product → | |
| 33 | 95701-06020-06 | BOLT FLANGE 6*20 | 4 | $2.25 USD | View product → | |
| 34 | 95701-06035-06 | BOLT FLANGE 6X35 | 4 | $6.24 USD | View product → | |
| 35 | 96001-06016-08G | BOLT FLANGE SH 6x16 (C) | 4 | $0.99 USD | View product → |
