F19 — Light Tail
The Light Tail diagram contains 18 genuine OEM parts for the KYMCO MAXXER 450i (2021). Hover a callout on the drawing to highlight the part in the list, click it to open the part, or click the drawing to zoom.
| # | Part | Name | Qty | Price | ||
|---|---|---|---|---|---|---|
| 1 | 33700-LGN5-900 | LIGHT ASSY R RR COMB | 1 | $135.30 USD | View product → | |
| 2 | 33701-LGN5-E00 | UNIT TAIL LIGHT R | 1 | $49.68 USD | View product → | |
| 3 | 33710-LGN5-900 | SOCKET COMP RR COMB | 1 | $70.17 USD | View product → | |
| 4 | 33731-PUA6-MX0 | REFLEX REFLECTOR | 2 | $19.26 USD | View product → | |
| 5 | 33745-LBA7-E00 | STAY REFLECTOR | 4 | $10.44 USD | View product → | |
| 6 | 33750-LGN5-900 | LIGHT ASSY L RR COMB | 1 | $135.30 USD | View product → | |
| 7 | 33751-LGN5-E00 | UNIT TAIL LIGHT L | 1 | $49.68 USD | View product → | |
| 8 | 33761-KHC5-M00 | REFLEX REFLECTOR | 2 | $14.01 USD | View product → | |
| 9 | 33761-PUA6-MX0 | REFLEX REFLECTOR, | 2 | $38.76 USD | View product → | |
| 10 | 34906-KPCP-900 | BULB TAIL & STOP | 2 | $8.76 USD | View product → | |
| 11 | 34906-KPCP-900-invalid | BULB TAIL & STOP | 2 | $11.40 USD | View product → | |
| 12 | 50211-LGC7-E00 | STAY REFLECTOR | 2 | $5.22 USD | View product → | |
| 13 | 90110-PWB1-900 | SCREW SPECIAL 6X20 | 4 | $7.17 USD | View product → | |
| 14 | 93903-25260 | SCREW TAPPING 5*12 | 8 | $1.86 USD | View product → | |
| 15 | 93903-35360 | SCREW TAPPING 5*16 | 6 | $3.78 USD | View product → | |
| 16 | 94050-05060 | NUT FLANGE 5MM | 4 | $4.92 USD | View product → | |
| 17 | 94050-06080 | NUT FLANGE 6MM | 2 | $2.31 USD | View product → | |
| 18 | 94050-LDE9-E00 | NUT LOCK | 4 | $2.61 USD | View product → |
