E06 — Starting Motor ● Oil Pump
The Starting Motor ● Oil Pump diagram contains 3 genuine OEM parts for the KYMCO LIKE 50 LX(2012~). Hover a callout on the drawing to highlight the part in the list, click it to open the part, or click the drawing to zoom.
| # | Part | Name | Qty | Price | ||
|---|---|---|---|---|---|---|
| 1 | 31200-LHM9-E10 | MOTOR ASSY STARTER | 1 | $210.75 USD | View product → | |
| 2 | 31209-GKAK-C00 | PINION ASSY STARTER | 1 | $83.10 USD | View product → | |
| 3 | 96001-06025-08 | BOLT FLANGE SH 6*25 | 2 | $2.61 USD | View product → |
